Self-clinching grounding pins for sheet metal

KVT-6,3-14

Type KVT-6,3-14
Flush head type with plug geometry according to DIN standard.

E-Shop

Technical Specification

Pin a x b

6.3 x 0.8

Material

Tin plated carbon steel.

Use

For sheet hardnesses up to HRB 80.

3D-Data available

Application

Self-clinching grounding pin for sheet material.

Order description

KVT-6,3-14

Hole-Ø in the sheet
+0.08
  0

6.4 mm

d

6.4 mm

L1

14.0 mm

L2 ±0.5

10.0 mm

sw

8.0 mm

Min. sm

0.8 mm

Min. edge distance up to the hole centre

7.2 mm

Tools

Identify order numbers of PEMSERTER® tools (anvils and punches): Tooling Selector

Insertion machines

Further information

Downloads

KVT 63 14_en 56.8 KB
